4 Channel Analog Voltage or Current Output Module Features: 4 Analog outputs 14-bit conversions Analog read-back Programmable slew rate Voltage or 4-20 mA output Specifications Output Type: mV, V, or mA Channels: 4 Voltage Range: 0 to 10Vdc, ±10Vdc, 0 to 5 Vdc, ±5Vdc Current Ranges: 0 to 20 mA and 4 to 20 mA Accuracy: ±0.1% of FSR Zero drift: ±15uV/°C (V out), ±0.2 uA/°C (I out) Span drift: 20 ppm/°C Programmable Slew Rate Voltage mode: 0.0625 to 64.9 V/sec Current mode: 0.125 to 128 mA/sec Analog Readback Channels: 1 connected to output Accuracy: ±1% of FSRGeneral Specifications:Power consumption: 2.4 W Operating temp: 14ºF to 158ºF Storage temperature: -13ºF to 185ºF Humidity: 5 to 95%, non-condensing

3 Channel RTD Input Module

14-Bit Isolated Input Modules (Inputs have common source) Feature:14 digital inputs Inputs share common source Low cost Description & Specifications:Input bits: 14 share common source Logic levels: LOW +1.0 VDC max, HIGH +3.5 to +30 VDC Input impedance: 3 kohm Input Isolation: 3000 Vrms Power consumption: 0.8 W Operating temp: 14ºF to 158ºF Storage temp: -13ºF to 185ºF

13-Bit Isolated Open Collector Output Module Feature:13 digital outputs (share common gnd) Open collector outputs Drives DR-OAC/ODC 100 mA outputs Description & Specifications:Outputs: 13 Output type: Open collector Output voltage: 30V max Output current: 100 mA max (enough output current to drive many types of relays) Isolation voltage: 3750V Power consumption: 0.8 W Operating temp: 14ºF to 158ºF Storage temp: -13ºF to 185ºF Humidity: 5% to 95%, non-condensing

16-Bit Non-Isolated Open Collector Output Module Feature:16 digital outputs (non-isolated) Open collector outputs Drives DR-OAC/ODC 100 mA outputs Description & Specifications:Outputs: 13 Output type: Open collector Output voltage: 30V max Output current: 100 mA max (enough output current to drive many types of relays) Isolation voltage: NONE Power consumption: 0.6 W Operating temp: 14ºF to 158ºF Storage temp: -13ºF to 185ºF Humidity: 5% to 95%, non-condensing

Isolated Digital I/O Module, 4 Input, 8 Output Features:4 digital input bits 8 digital output bits Low power consumption Description & Specifications:Input bits: Isolated (share common gnd) Logic levels: LOW +1.0 VDC max, HIGH +3.5 to +30 VDC Output bits: 8 Output config: Open collector Max voltage: 30 V Output current: 600 mA max. (3 A total max) Power consumption: 0.8 W Operating temp: 14ºF to 158ºF Storage temp: -13ºF to 185ºF

15-Bit Digital I/O Module, 7-Bits Input, 8-Bits Output Features:4 digital input bits 8 digital output bits Low power consumption Description & Specifications:Input bits: Isolated (share common gnd) Logic levels: LOW +1.0 VDC max, HIGH +3.5 to +30 VDC Output bits: 8 Output config: Open collector Max voltage: 30 V Output current: 600 mA max. (3 A total max) Power consumption: 0.8 W Operating temp: 14ºF to 158ºF Storage temp: -13ºF to 185ºF

Isolated 8-Bit Digital Input Module Feature:Isolated inputs 8 inputs 6 fully isolated 2 share common ground High voltage inputs Description & Specifications:Input bits: 8, 6 fully isolated, 2 share common ground Logic levels: LOW +1.0 VDC max, HIGH +3.5 to +30 VDC Input impedance: 3 kohm Input Isolation: 3000 Vrms Power consumption: 0.4W Operating temp: 14ºF to 158ºF Storage temp: -13ºF to 185ºF
