Automation Industrielle | controleurs programmables
I-8017HS
14-bit 100K sampling rate 8/16-channel analog input module FEATURES: 14-bit 100K sampling rate 8/16-channel analog input module SPECIFICATIONS: Parallel I/O Module Resolution: 14-bit Input impedance: 10M£[ Accuracy: 0.1% of FSR Isolation Voltage: 3000Vdc Power Consumption: 2W
Appelez-nous
I-8024G
FEATURES: 4-channel Isolated Analog Output Module SPECIFICATIONS: Parallel I/O Module Resolution: 14-bit Output Range: 0 ~ 20 mA, +/- 10V Accuracy: +/- 0.1% of FSR for voltage output, +/- 0.2% of FSR for current output
$579.00
I-8037G
FEATURES: 16-channel Isolated Open-Drain Output Module SPECIFICATIONS: Output Type : Open-Drain (source) Outputs per Module : 16 Channels Load Voltage : 30VDC (maxinum) Load Current per Channel : 100mA (maxinum) Isolation Voltage : 3750Vrms 1 LED with power 16 LEDs with digital output Power consumption: 0.5W
$289.00
I-8040
FEATURES: 32-channel Isolated Digital Input Module SPECIFICATIONS: Digital input channels: 32 3750V isolation ( External power) 3000V isolation ( Internal power) Input Voltage: 3.5V ~ 30 V Response time: 1 KHz Max.
$394.00
I-8040G
FEATURES: 32-channel Isolated Digital Input Module SPECIFICATIONS: Digital input channels: 32 3750V isolation ( External power) 3000V isolation ( Internal power) Input Voltage: 3.5V ~ 30 V Response time: 1 KHz Max.
$389.00
I-8041G
FEATURES: 32-channel Isolated Digital Output Module SPECIFICATIONS: Digital Output channels: 32 3750V isolation Open-collector Output: 125 mA/ channel Response time: 1 KHz Max. Load Current: 100mA Power Consumption: 1.7W
$389.00
I-8042G
FEATURES: 16-channel Isolated Digital Input & 16-channel Isolated Digital Output Module SPECIFICATIONS: Digital Input channels: 16 Digital Output channels: 16 Load Voltage : 5Vdc to 30Vdc Load Current : 100mA (maximum) Isolation Voltage : 3750Vrms Other specifications are similar to I-8040 and I-8041 Power consumption: 1.5W
$389.00
I-8048
8-channel Digital lnput with lnterrupt Module FEATURES: Parallel I/O Module Rising/Falling edge interrupt programmable LED indicator for each channel of digital input SPECIFICATIONS: Isolation Voltage:2000V Digital Input Channels: 8 Built-in isolated power supply: 5V, 200mA max. Input impedance: 10MΩ Logic High level: Isolated: 4V ~30V Non-Isolated TTL: 2V ~ 5V Power Consumption: 0.8W Logic Low level: Isolated: 0 ~1V Non-Isolated TTL: 0V~ 0.8V
Appelez-nous
